Metal Roll Forming Machine

Product Details:

Computerized Yes
Share Your Product:

36000-110000 USD ($)/Set

Get a Price/Quote

Request To Call Back Send Inquiry

Metal Roll Forming Machine Price And Quantity

Minimum Order Quantity 1 Set
Price Range 36000.00 - 110000.00 USD ($)/Set
Price 36000-110000 USD ($)/Set

Metal Roll Forming Machine Product Specifications

Computerized Yes

Metal Roll Forming Machine Trade Information

Supply Ability 20 Set Per Year
Delivery Time 90 Days

Product Description

We are considered as the most reliable most famous exporter, manufacturer, trader and supplier,of a wide range of Metal Roll Forming Machine. These machines are composed and fabricated remembering all the set quality standards of the business. Our range of Metal Roll Forming Machine is best acclaimed for qualities, for example, against rust roller: CNC machine tooled, plated with 0.05mm hard chrome , heat treatment, cutter edge, high exactness, guarantee accuracy execution, individuals begin, superb administrations etc.

Detailed Product Description :

Material Of Cutter:	Cr12 Mould Steel With Quench Treatment, HRC58-60
Material Of Shaft:	High Quality 45# Steel
Hydraulic Power:	5.5kw
Machine's Installation Size:	35000X1800X2000mm (l x w x h)
Controller:	Mitsubishi PLC
Material Of Forming Rollers:	Cr12 Mould Steel Being Quenched Treatment
Main Power:	11KW
Production Speed:	About 5m/min.
Punching:	Automatic Punching Continuously
Cutting Style:	Automatic Hydraulic Cutting

PLC Automatic Metal Roll forming Machine For Supermarket Shelves

Technical data of shelving cold roll forming machine :

Suitable raw material	Q235A galvanized steel sheet; thickness:2.0-2.5mm
Forming speed	about 7-10m/min.
Production speed	About 3-5 m/min.
Material of forming rollers	Cr12 mould steel being quenched treatment,
Material of cutter,punching die	Cr12 mould steel with quench treatment, HRC58-60
Material of shaft	High quality 45# steel with heat treatment. Roller grinder milling.
Main power	11 KW
Total motor power	about 19 Kw(Depend on final design)
Control system	Mitsubishi PLC & converter

Item		Specification
	Type	Galvanized coils
Material	Thickness (mm)	0.5-1.5
	Yield strength (mpa)	235
Roller material		45#Chrome steel
Forming speed(m/min)		About 15-20
Speed adjusting mode		AC Frequency
Roller drive		Decelerating motor + Chain drive
Cutting mode		Hydraulic cutting
Cutter material		Cr12 mould steel
Length measurement		Encoder
Control mode		Mitsubishi PLC
Operating mode		Button + Mitsubishi Touch screen
Main motor power (kw)		5.5 kw (Depend on final design)
Hydraulic station power		2.2 kw (Depend on final design)
Total power (kw)		7.7 kw
Uncoiler's loading capacity		Max. Capacity: 3000kgs
Components of machine
			Decoiler	1set
Feeding & guiding device		1set
Main roll forming machine		1set
Punching device		1set
Hydraulic cutting system		1set
Controlling system		1set
Run out table		1set
Process flow:
			Decoiler -- Feeding & Guiding -- Roll Forming-- Punching--Hydraulic Cutting – Product to Run Out Table
