Shutter Door Forming Machine

Product Details:

Computerized Yes
Share Your Product:

36000-110000 USD ($)/Set

Get a Price/Quote

Request To Call Back Send Inquiry

Shutter Door Forming Machine Price And Quantity

Price Range 36000.00 - 110000.00 USD ($)/Set
Minimum Order Quantity 1 Set
Price 36000-110000 USD ($)/Set

Shutter Door Forming Machine Product Specifications

Computerized Yes

Shutter Door Forming Machine Trade Information

Supply Ability 20 Set Per Year
Delivery Time 90 Days

Product Description

Banking upon our rich industrial experience, we as a noticeable manufacturer, trader and supplier, are occupied with offering our customers with a thorough assortment of Shutter Door Forming Machine which can make roller shade entryways with high security. This frothing machine is outfitted with Double head rack which enhance the stacking effectiveness. It is broadly utilized as a part of mechanical and additionally business fields, airplane terminals, inns, shopping centers and malls. Our array of Shutter Door Forming Machine embraces s PLC and inverter controller which help to enhance the working productivity.

Detailed Product Description :

Main Motor:	5.5KW	Hydraulic Power:	2.2KW
Roller Material:	High Quality 45# Steel, Plated With Chrome On Surface	Material Of Cutter:	Cr12 Mould Steel Being Quenched Treatment
Shaft For Rollers:	55mm Solid Steel	Forming Speed:	About 20m/min.
Punching:	For Option	Controller:	Mitsubishi PLC
Machine's Size:	6500x1200x1500mm(LxWxH)	Guarantee:	Two Year Guarantee, Lifetime Services

High Precision Metal Shutter Door Forming Machine 20m / min 0.4mm - 0.8mm

Technical data of Shutter Door cold roll forming machine :

Suitable Material	Galvanized steel strip
Thickness of raw material	0.4-0.8mm (235-345Mpa)
Material of roller	45# steel being quenched treatment
Material of cutter blade	Cr12 mould steel with quenched treatment, HRC58-60
Material of shaft	High quality 45# steel with heat treatment. Roller grinder milling.
Forming speed	about 20m/min
Power Requirement	Main motor power: 4Kw(Depend on final design)
	Hydraulic station power: 2.2Kw (Depend on final design)
Diameter of shaft for rollers	55mm
Controlling system	Mitsubishi PLC & converter
Quantity of rollers	About 12 stations for main rollers
Weight of machine	About 3500KGS
Size of machine installation	about 12mx 1.7 mx1.5m

Product Feature: The product from the roll forming machines is used as shutter door of building. Punching or without punching can be chose.

Components of machine

Shutter door forming machine includes in decoiler, sheet guiding equipment, roll forming system, post-cutting equipment, hydraulic station, electric controlling system and run out table for product.
