Send InquiryShutter Door Roll Forming Machine
Product Details:
- Computerized Yes
- Automatic Grade Automatic
- Control System PLC Control
- Rolling Speed 20-25 m/m
- Cutting System Hydraulic cutting
- Cutting Thickness 0.3-0.8 Millimeter (mm)
- Voltage 415 Volt (v)
Shutter Door Roll Forming Machine Price And Quantity
- 1 Set
- 19000-25000 USD ($)/Set
- 19000.00 - 25000.00 USD ($)/Set
Shutter Door Roll Forming Machine Product Specifications
- PLC Control
- Hydraulic cutting
- Yes
- Automatic
- 20-25 m/m
- 415 Volt (v)
- 0.3-0.8 Millimeter (mm)
- 12months
Shutter Door Roll Forming Machine Trade Information
- Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T)
- 20 Set Per Year
- 90 Days
- Eastern Europe, Middle East, South America, Western Europe, Asia, Central America, North America, Australia, Africa
Product Description
To meet huge demands of our valued clients, we are successfully affianced in putting-forward the best quality array of Shutter Door Roll Forming Machine. Our offered machine is manufactured with the use of optimum quality components with the consistent improvisation of pioneering technology at par with the international quality standards. Our range of machine is used for manufacturing of shutter doors that find applications in various commercial places for security purposes. Apart from this, our esteemed clients can easily purchase this Shutter Door Roll Forming Machine at negotiable prices from us.
Features:
- Vibration and impact resistance
- Low power consumption
- High efficiency
- Needs least maintenance
Detailed Product Description :
|
Main Motor: |
5.5KW |
|
Roller Material: |
High Quality 45# Steel, Plated With Chrome On Surface |
|
Shaft For Rollers: |
55mm Solid Steel |
|
Punching: |
For Option |
|
Machine's Size: |
6500x1200x1500mm(LxWxH) |
|
Hydraulic Power: |
2.2KW |
|
Material Of Cutter: |
Cr12 Mould Steel Being Quenched Treatment |
|
Forming Speed: |
About 20m/min. |
|
Controller: |
Mitsubishi PLC |
|
Guarantee: |
Two Year Guarantee, Lifetime Services |
Professional Cold Shutter Door Roll Forming Machine 12m x 1.7 m x 1.5m
Technical data of Shutter Door cold roll forming machine
|
Suitable Material |
Galvanized steel strip |
|
Thickness of raw material |
0.4-0.8mm (235-345Mpa) |
|
Material of roller |
45# steel being quenched treatment |
|
Material of cutter blade |
Cr12 mould steel with quenched treatment, HRC58-60 |
|
Material of shaft |
High quality 45# steel with heat treatment. Roller grinder milling. |
|
Forming speed |
about 20m/min |
|
Power Requirement |
Main motor power: 4Kw(Depend on final design) |
|
|
Hydraulic station power: 2.2Kw (Depend on final design) |
|
Diameter of shaft for rollers |
55mm |
|
Controlling system |
Mitsubishi PLC & converter |
|
Quantity of rollers |
About 12 stations for main rollers |
|
Weight of machine |
About 3500KGS |
|
Size of machine installation |
about 12mx 1.7 mx1.5m |
