Cable Tray Forming Machine

Product Details:

Computerized Yes
Share Your Product:

36000-110000 USD ($)/Set

Get a Price/Quote

Request To Call Back Send Inquiry

Cable Tray Forming Machine Price And Quantity

Price 36000-110000 USD ($)/Set
Minimum Order Quantity 1 Set
Price Range 36000.00 - 110000.00 USD ($)/Set

Cable Tray Forming Machine Product Specifications

Computerized Yes

Cable Tray Forming Machine Trade Information

Supply Ability 20 Set Per Year
Delivery Time 90 Days

Product Description

We are the counted among the well known manufacturer, trader, supplier and exporter of Cable Tray Forming Machine. To manufacture this machine, our professionals use quality tested raw materials and latest technology in accordance with set industrial norms. This machine is used for producing cable trays that are used in various kind of factories and buildings. In addition to this, C Channel Cable Tray Forming Machine is provided to our customers at industrial leading prices. Following are some features of this forming machine:

Easy installation
Negligible maintenance
User friendly design
Longer working life

Detailed Product Description :

Roller Material:	No.45 Steel, Plated With Chrome On Surface.	Cutter Material:	Cr12 Mould Steel
Main Motor:	5.5KW	Hydraulic Power:	5.5KW
Controller:	Mitsubishi PLC, Screen	Cutting Style:	Automatic Cut To Length
Punching:	For Option	Machine's Size:	7500X1200X1500mm (LXWXH)
Forming Speed:	About 20m/min.	Guarantee:	Two Years Guarantee Time, Lifetime Service

Steel Strip Stud and Track Roll Forming Machine / Metal Forming Equipment

Technical data of Stud & track cold roll forming machine :

Suitable Material	Cold-rolled steel strip and heat-treated galvanized steel strip
Thickness of raw material	0.5-0.8mm (235-345Mpa)
Material of roller	45# steel being quenched treatment
Material of cutter blade& punching die	Cr12 mould steel with quenched treatment, HRC58-60
Material of shaft	High quality 45# steel with heat treatment. Roller grinder milling.
Forming speed	about 20m/min
Power Requirement	Main motor power: 5.5 Kw(Depend on final design)
	Hydraulic station power: 5.5Kw (Depend on final design)
Diameter of shaft for rollers	55mm
Controlling system	Mitsubishi PLC & converter
Quantity of rollers	about 15 stations for main rollers
Weight of machine	About 5500KGS
Size of machine installation	about 15m x 1.7 m x1.5m
