Send InquiryMetal Roof Roll Forming Machine
Product Details:
- Computerized Yes
Metal Roof Roll Forming Machine Price And Quantity
- 36000-110000 USD ($)/Set
- 1 Set
- 36000.00 - 110000.00 USD ($)/Set
Metal Roof Roll Forming Machine Product Specifications
- Yes
Metal Roof Roll Forming Machine Trade Information
- 20 Set Per Year
- 90 Days
Product Description
We are counted as a distinct and eminent manufacturer, exporter and supplier of Metal Roof Roll Forming Machine. The offered machine finds its applications in varied industries for making roof role. Accessible in several technical specifications, the offered Metal Roof Roll Forming Machine is manufactured under our experts’ supervision by utilizing the best grade components. In addition, the provided machine can be easily availed from us at marginal prices.
Features
- Power efficient
- Low noise generation
- Advanced electric control system
- Easy and safe to operate
Metal Roof Roll Forming Machine
Detailed Product Description :
| Machine's Size: | 9500X1800X1500mm (LxWxH) | Main Power: | 7.5KW |
| Cutting Style: | Automatic Cutting | Roller Material: | No.45 Steel, Plated With Chrome |
| Cutter Material: | Cr12 Mould Steel | Controlling System: | Mitsubishi PLC, Screen |
| Shaft For Roller: | 72mm Dia. Solid Steel | Guarantee: | One Year Guarantee Time, Lifetime Service |
| Quality System: | ISO 9001 | Forming Speed: | About 20m/min. |
India Trapezoidal Sheets Metal Roof Roll Forming Machine with ISO 20m / min
Technical data of Trapezoidal sheets roll forming machine
| Suitable material | Q235 color steel sheet;0.3-0.7mm, 1000&1250mm coil width |
| Forming speed | about 20m/min |
| Power Requirement | Main motor power: 7.5 Kw(Depend on final design) |
|
| Hydraulic station power: 2.2Kw(Depend on final design) |
| Material of forming rollers | No.45 steel, plated with chrome on sureface. |
| Material of cutter | Cr12 mould steel with quench treatment, HRC58-60 |
| Material of shaft | High quality 45# steel with heat treatment. |
| Shaft diameter | 72mm |
| Controlling system | Mitsubishi PLC & converter |
| Total weight of machine | About 8500KGS |
| Machines size | about 15m x 1.8m x 1.5m (Depend on final design) |
| Shipping | 1x40GP container can load one machine |
