Send InquiryAluminium Roofing Sheet Making Machine
Product Details:
- Computerized Yes
36000-110000 USD ($)/Set
X
Aluminium Roofing Sheet Making Machine Price And Quantity
- 36000-110000 USD ($)/Set
- 36000.00 - 110000.00 USD ($)/Set
- 1 Set
Aluminium Roofing Sheet Making Machine Product Specifications
- Yes
Aluminium Roofing Sheet Making Machine Trade Information
- 20 Set Per Year
- 90 Days
Product Description
With quality devoted approach, our organization is engrossed in manufacturing, exporting and supplying top quality Aluminium Roofing Sheet Making Machine. This machine is mainly used for making aluminium roofing sheets of desired cross-section. The offered machine is manufactured with efficiency under our experts’ direction by utilizing the superior grade components. Besides, the provided Aluminium Roofing Sheet Making Machine can be bought from us at competitive rates.
Features:
- Corrosion proof body
- Rugged design
- Designed with a roller and cutting system
- High speed functioning
Aluminium Roofing Sheet Making Machine
Machine components:
- Decoiler (manual decoiler and hydraulic decoiler for option) : 1 set
- Feeding & guiding device : 1 set
- Main roll forming machine: 1 set
- Hydraulic cutting system : 1 set
- Controlling system : 1 set
- Run out table (auto. Stacker for option) : 2 pcs
Machine material
- Electric elements: Mitsubishi PLC & transducer from Japan.
- Anti-rust roller: No. 45 forged steel. Plated with 0.05mm hard chrome
- Well resisting active shaft: High grade No. 45 carbon wrought steel.
- Cutter blade: Cr12 mould steel with quenched treatment
- Precision: shafts are tooled by grinding machine at least twice. Rollers are CNC processed.
Parameter
| Item | Specification | |
| Material | Type | Pre-painted steel coil & galvanized coils |
| Thickness (mm) | 0.4-0.7 | |
| Yield strength (mpa) | 235-345 | |
| Roller material | 45#Chrome steel | |
| Forming speed(m/min) | About 20 | |
| Cutter material | Cr12 mold steel | |
| Main motor power (kw) | 7.5 kw (Depend on final design) | |
| Hydraulic station power | 2.2 kw (Depend on final design) | |
| Uncoiler's loading capacity | Max. Capacity: 5000kgs (can be increased to be 10T) | |
| Machine`s size | About 10 x 1.6 x 1.6m (Depend on final design) | |
