Corrugated Roof Sheet Making Machine

Product Description

Corrugated Roof Sheet Making Machine

Due to our experienced crew of professionals, we are able to manufacture, export and supply a wide range of Corrugated Roof Sheet Making Machine. Checked by our quality inspectors on varied quality aspects, the provided machine is manufactured with the help of pioneering technology by utilizing supreme quality components. The provided machine is highly demanded for making roofing sheets of desired dimensions. Also, this Corrugated Roof Sheet Making Machine is accessible for our precious patrons at reasonable prices.

Features:

• Hassle free installation

• High speed functioning
• Trouble free performance
• Easy to maintain


About Corrugated Roof Sheet Making Machine:

• Material:color steel sheet
• Yield strength: 235Mpa
• Thickness: 0.4-0.7mm
• Forming Speed:20m/min.
• Main motor power: 7.5Kw(Depend on final design)
• Hydraulic station power: About 2.2Kw (Depend on final design)
• Manual decoiler Max. Capacity: 5000kgs
• Power 380V/3Phase/ 50Hz



Machine spec.

• Size: about 8.5 x 1.4 x 1.5m (L x W x H)
• Weight: About 7ton
• Rolling station: 16stations

Machine material

• Electric elements: Mitsubishi PLC & transducer from Japan.
• Anti-rust roller: No. 45 forged steel. Plated with 0.05mm hard chrome
• Well resisting active shaft: High grade No. 45 carbon wrought steel.
• Cutter blade: Cr12 mould steel with quenched treatment
• Precision: shafts are tooled by grinding machine at least twice. Rollers are CNC processed.

Process flow:

• Decoiler -- Feeding & Guiding -- Roll Forming-- Hydraulic Cutting – Product to Run Out Table

Packing: 1 x 40ft container

Raw Material:

• Material: color steel sheet
• Yield strength: 235Mpa
• Thickness: 0.4-0.7mm



Machine components:

• Decoiler (manual decoiler and hydraulic decoiler for option) : 1 set
• Feeding & guiding device : 1 set
• Main roll forming machine : 1 set
• Hydraulic cutting system : 1 set
• Controlling system : 1 set
• Run out table (auto. Stacker for option) : 2 pcs

We customize your machines!

To customize machine, we would love to know:

• Profile drawing
• Raw material: the width(1250mm?), thickness(0.3-0.7mm?), and yield strength of steel coil.
• Voltage: designed per your requirement
• Configuration requirement: Hydraulic or manual decoiler/ stacker

Why us?

• Customize roll forming machines since 2003.
• Capacity: 12-15 sets/month
• Delivery: in only 5-8 weeks for urgent order
• Company occupies 6650, in which 5650 for workshops
• Have our own tool center. 12 sets CNC machines.
• Technician can be sent to your factory to install the machine and train your workers
• Zhongyuan is a "All-in-house source" from raw material to the final high-precision forming machine. We have our precise tooling center.

Product Feature:

• The product formed by this roll forming machines looks beautiful and widely used as the roof of garden, factory, hotel, exhibition center,etc

Why choose this machine?

• Certificate: ISO 9001, CE,
• Lifetime services
• 72mm diameter solid steel shaft. Roller cover with 0.05mm chrome; Lifetime>10years.
• Introduced Mitsubishi PLC with touch screen to machine controll system.
• One worker operation (minimum)
• Heat treatment:Cutting blade.  Quenched treatment: Cr12 mould steel cutter
• Product cut-to-length.
• Technician overseas installing and training available



Process flow:

• Decoiler -- Feeding & Guiding -- Roll Forming-- Hydraulic Cutting  Product to Run Out Table
