Send InquiryRidge Cap Cold Roll Forming Machine
Product Details:
- Type ZYYX130-315 ridge cap machine
- Computerized Yes
- Automatic Grade Automatic
- Control System PLC Control
- Rolling Speed about 15-20m/min (without press and cut time) m/m
- Voltage 415 Volt (v)
- Dimension (L*W*H) 5.8mX1.15mx1.75m Meter (m)
18000-46000 USD ($)/Set
X
Ridge Cap Cold Roll Forming Machine Price And Quantity
- 18000.00 - 46000.00 USD ($)/Set
- 1 Set
- 18000-46000 USD ($)/Set
Ridge Cap Cold Roll Forming Machine Product Specifications
- 4200 Kilograms (kg)
- 12month
- ZYYX130-315 ridge cap machine
- 5.8mX1.15mx1.75m Meter (m)
- PLC Control
- Automatic
- about 15-20m/min (without press and cut time) m/m
- Yes
- 415 Volt (v)
Ridge Cap Cold Roll Forming Machine Trade Information
- Letter of Credit (L/C), Telegraphic Transfer (T/T)
- 50 Set Per Year
- 60 Days
- North America, Central America, Middle East, South America, Asia, Africa
- All India
Product Description
Attributable to our enormous business experience and learning, we as a prominent manufacturer, trader and supplier, are occupied with offering Ridge Cap Cold Roll Forming Machine to our clients. This machine comprise of machine casing, electrical engine, transmission framework, and move shaping framework. It can move structure metal edge which is generally utilized with beautiful material tile sheets. In addition to this, the surface of coated tile will be smooth-textured and lovely with no scratch on surface. Offered in different particulars, this Ridge Cap Cold Roll Forming Machine is offered to our clients at business sector driving costs.
Technical data of ridge cap roll forming machine:
| Suitable Material | Q235 color steel sheet;0.4-0.6mm |
| Working speed | About 3.0m/min |
| Step distanc | adjustable according to requirement (>=250mm) |
| Power Requirement | Main motor power: 5.5 Kw(Depend on final design) |
| | Hydraulic station power: 5.5Kw(Depend on final design) |
| Material of forming rollers | No.45 steel, plated with chrome on surface. |
| Material of cutter,pressing die | Cr12 mould steel with quench treatment, HRC58-60 |
| Material of shaft | High quality 45# steel, Dia. is 72mm. |
| Shaft diameter | 72mm |
| Controlling system | Mitsubishi PLC & converter |
| Total weight of machine | About 10500KGS |
| Size of machine installation | About 18mx1.8mx 1.5m (Depend on final design) |
