Send InquiryGuardrail Roll Forming Machine
Product Details:
- Computerized Yes
- Automatic Grade Automatic
- Control System PLC Control
- Rolling Speed 20-25 m/m
- Cutting System Hydraulic cutting
- Cutting Thickness 0.8-2.0 Millimeter (mm)
- Voltage 415 Volt (v)
Guardrail Roll Forming Machine Price And Quantity
- 82000.00 - 89000.00 USD ($)/Set
- 82000-89000 USD ($)/Set
- 1 Set
Guardrail Roll Forming Machine Product Specifications
- 20-25 m/m
- Hydraulic cutting
- Yes
- 14*1.8*1.6 Meter (m)
- Automatic
- 0.8-2.0 Millimeter (mm)
- 12months
- 200000 Kilograms (kg)
- 415 Volt (v)
- PLC Control
Guardrail Roll Forming Machine Trade Information
- Ningbo
- Letter of Credit at Sight (Sight L/C), Telegraphic Transfer (T/T)
- 20 Set Per Year
- 90 Days
- Western Europe, Australia, North America, South America, Eastern Europe, Middle East, Central America, Asia, Africa
Product Description
Guardrail Forming Machine (Guardrail Roll Forming Machine)
By keeping the track of most recent business sector advancement, we as a prime manufacturer, trader and supplier, are occupied with offering Guardrail Forming Machine to our clients. This machine is predominantly comprise of decoiler, move framing system,cutting hardware, leveling framework, punching gear, water powered station, control framework and item supporter. Our experts make this machine with Q235A aroused steel sheet having thickness of 2-3.0mm. Broadly known for its low support, long time span of usability, unwavering quality and solid plan, this Guardrail Forming Machine is exceptionally requested in the business sector.
Machine`s components: Highway guardrail forming machine mainly consists of decoiler, leveling system, punching equipment, roll forming system, cutting equipment, hydraulic station, control system and product supporter.
Main Technical Parameters:
- Suitable raw material: Q235A galvanized steel sheet; thickness:2-3.0mm
- Total motor power: about 35Kw(Depend on final design)
- Forming speed: about 8-10m/min.
- Material of forming rollers: Cr12 mould steel being quenched treatment
- Material of cutting die: Cr12 mould steel with quenched treatment
- Control system: Mitsubishi PLC & converter
|
Technical Details |
|
|||
|
Item |
Specification |
|
||
|
|
Type |
galvanized steel sheet |
|
|
|
Material |
Thickness(mm) |
2.0-3.2 |
|
|
|
|
Yield strength |
Q235 or 34Ksi |
|
|
|
Roller material |
GCr15 bearing steel with quench treatment |
|
||
|
Forming speed(m/min) |
About 1500-2000mm/min or 4-5m/min. For option |
|
||
|
Step distance |
Adjustable according to requirement (>=250mm) |
|
||
|
Speed adjusting mode |
AC Frequency |
|
||
|
Roller drive |
Decelerating motor + Chain drive |
|
||
|
Type of cutting |
after roll-formed and length-set cutting |
|
||
|
Cutter material |
Cr12 mould steel quench treatment |
|
||
|
Length measurement |
Encoder |
|
||
|
Control mode |
Mitsubishi PLC |
|
||
|
Operating mode |
Button + Mitsubishi Touch screen |
|
||
|
Components of CE Steel Guardrail Cold Roll Forming Machine |
|
|||
|
Decoiler |
1set |
|
||
|
Feeding & guiding device |
1set |
|
||
|
Punching device |
1set |
|
||
|
Main roll forming machine |
1set |
|
||
|
Hydraulic station |
1set |
|
||
|
Controlling system |
1set |
|
||
|
Run out table |
1set |
|
||
|
Process flow: |
|
|||
|
Decoiler -- Feeding & Guiding --Roll Forming--Punching-- Hydraulic Cutting - Product to Run Out Table |
||||
